- Double walled construction with inner chamber, outer chamber and support ring are fully made of stainless steel.
- Heater’s cover stand and carrier/bucket are made of stainless steel.
- Lid made of thick machined stainless-steel plate.
- Radial locking lid ensures user safety and safe locking.
- Lid is fitted with pressure gauge, spring loaded safety valve, double safety valve, manual exhaust valve, vacuum breaker as a safety device and water level indicator.
- Drain valve facilitates easy cleaning of the chamber.
- Molded joint less silicon rubber gasket.
- All internal joints are argon arc welded, ground and polished to give crevice free internals.
- Miniature circuit breaker for mains on/off plus safety of control panel.
- Industrial grade energy efficient heaters reduce power bill drastically.
- Gasket: Made of joint less silicon rubber.
- Exhaust pressure: Manual through the exhaust valve Sterilizing, 20 psi) at 121°C
- Operating pressure: From 15 psi to 20 psi
- Pressure gauge: SS 304 Grade Stainless Steel
- Pressure Vessel: SS 304 Grade Stainless Steel
- External Wall: SS 304 Grade Stainless Steel
- Top Lid: SS 304 Grade Stainless Steel
- Basket: High Grade Stainless Steel
- Works on 230±10V/50Hz power supply
| Model No. | LBX-319 (A) | LBX-319 (B) | LBX-319 (C) | LBX-319 (D) | LBX-319 (E) | LBX-319 (F) |
| Dimension (inch) | 10 x 18 | 12 x 22 | 14 x 22 | 16 x 24 | 18 x 24 | 22 x 30 |
| Inner Dimension | 250 x 450 | 300 x 550 | 350 x 550 | 400 x 600 | 450 x 600 | 550 x 750 |
| Capacity | 22 Liters | 40 Liters | 50 Liters | 78 Liters | 98 Liters | 180 Liters |
| Heater Load | 1.5 KW | 2 KW | 3 KW | 4 KW | 4 KW | 6 KW |
