- Fully Automatic Autoclave useful to sterilizer lab glassware, plastic Tubing, Liquid in sealed glass containers and many more uses.
- Fully Argon welded to avoid steam and pressure leak.
- Double walled construction with inner stainless steel Outer body made up of mild steel duly powder coated.
- Unique single lever lock ensures easy lifting & closure of Autoclave door without leakage of vacuum & Pressure.
- Temperature. is being controlled by Microprocessor based PID Controller with Dual Digital Indicator
- Highly accurate P.T.-100 temperature sensor used.
- Cycle begins with press of start switch for fully automatic operation.
- Automatic steam and air exhaust at end of cycle.
- Specially designed heaters reduces power consumption.
- Removable SS 304 Rod type basket is provided.
- Water low level Alarm indication and heater cut of facility.
- Lid is equipped with pressure gauge range 0 to 20 PSI.
- Safety valve, Steam release Exhaust Valve, vacuum breaker for more safety.
- Temperature Range: 121°Cup to 135°C
- Temperature Accuracy: ± 1°C
- Pressure Range: 0 to 21 PSI or 0 to 30 PSI
- Pressure Accuracy: ± 1.2 PSI.
- Works on 230±10V/50Hz power supply.
| Model No. | LBX-318 (A) | LBX-318 (B) | LBX-318 (C) | LBX-318 (D) | LBX-318 (E) | LBX-318 (F) |
| Dimension (inch) | 10 x 18 | 12 x 22 | 14 x 22 | 16 x 24 | 18 x 24 | 22 x 30 |
| Inner Dimension | 250 x 450 | 300 x 550 | 350 x 550 | 400 x 600 | 450 x 600 | 550 x 750 |
| Overall Capacity | 30 Liters | 43 Liters | 64 Liters | 91 Liters | 135 Liters | 212 Liters |
| Working Capacity | 22 Liters | 40 Liters | 50 Liters | 78 Liters | 98 Liters | 180 Liters |
| Load | 1.5 KW | 2 KW | 3 KW | 4 KW | 4 KW | 6 KW |
