| Wavelength Range | 190-1100nm |
| Spectral Bandwidth | 2 nm |
| Optical System | Single Beam, grating 1200 lines/mm |
| Wavelength Accuracy | ±0.2nm |
| Wavelength Repeatability | ±0.1 nm. |
| Wavelength Resolution | ±0.1 nm. |
| Photometric Accuracy | ± 0.5 %T or ± 0.003 A@1A |
| Photometric Range | – 0.3 to 3A, 0-200% T, 0-9999 Conc. |
| Stray Light | ≤0.3 %T |
| Stability | ±0.002 A/H @ 500 nm |
| Display | 128 X 64 Dots Large Graphical LCD |
| Keyboard | Soft Touch Membrane Keys |
| Photometric Mode | % Transmission, Absorbance and Concentration |
| Detector | Silicon Photodiode |
| Sample Compartment | Standard 4-Position 10 mm path-length cuvette holder. (Accommodates upto 100mm path- length cuvette with optional holder) |
| Light Source | Tungsten and Deuterium Lamps |
| Output | USB for PC Connectivity and Parallel Part for Dot Matrix printer |
| PC software | Basic PC Software provided for quantitative /kinetic analysis with professional PC Software for additional wavelength scan and DNA/Protein Test. |
| Power | 230v ±10% AC, 50Hz |
| Dimension Instrument | 700 x 550 x 340 mm (L x B x H) (Approx.) |
Salient Features
- Covers 190 to 1100nm
- 4 Position Cuvette Holder
- Automatic Wavelength Selection
- 128 x 64 Graphical LCD
- Printer Interface
- USB Computer Interface
- With Professional Scanning Software
Standard Accessories
- Quartz Cuvettes – A Set of 2
- Glass Cuvettes – A Set of 4
- Instruction Manual
- Software Manual
- Software CD
- USB Data Cable for PC Connectivity
- Mains Lead
- Dust Cover
