- Sterilizer uses Ethylene oxide to sterilize heat or moisture-sensitive devices.
- All sensors linked to the automation ensure reliable operation.
- Screen on the control panel indicates a specific phase during the operation.
- Negative chamber pressure ensures that gas cannot escape into the operating area. Locked door sensor during cycle.
- Constant watch over entries and break diagnostic from automation which warns the operator by means of messages on indicator and buzzer.
- Cycle completion record is shown on the printout.
- Chamber and cabinet made of high grade stainless steel.
- Fully Automatic PLC display 7′ color touch screen.
- The Sterilization is a one-touch operation where the operator loads the material in the trolley provided along with the machine, closes the door, and then presses the Start button to initiate the cycle; the cycle then continues on its own, and after sterilizing and aerating the load; informs the operator that the cycle is complete.
- Once stored, this program cannot be modified by invoking the password command.
- With heating, vacuum and humidity system.
- With air inlet filter.
- Works on 230±10V/50Hz power supply.
| Model No. | LBX-313 (A) | LBX-313 (B) | LBX-313 (C) | LBX-313 (D) |
| Dimension (inch) | 12x12x24 (LBH) | 12X12X36 (LBH) | 12x12x48 (LBH) | 24x24x48 (LBH) |
| Dimension (mm) | 300X300X600 | 300X300X900 | 300X300X1200 | 600X600X1200 |
| Capacity in LTR | 54 LTR | 85 LTR | 108 LTR | 432 LTR |
