- Inner Chamber & outer chamber are fully made of stainless steel.
- Heater cover stand & carrier/bucket are made of stainless steel.
- Lid made of thick machined stainless steel plate.
- Lid is fitted with pressure gauge, spring loaded safety valve, double safety valve, manual exhaust valve, vacuum breaker as a safety device & water level indicator.
- Drain valve facilitates easy cleaning of the chamber.
- Molded joint less silicon rubber gasket.
- All internal joints are argon arc welded, ground & polished to give crevice free Internals.
- Miniature circuit breaker for mains ON/OFF plus safety of control panel.
- Industrial grade energy efficient heaters reduce power bills drastically.
- Works on 230±10V/50Hz power supply.
| Working Pressure | 15-20 PSI |
| Working Temperature | 121-125°C |
| Power Supply | 220x230V AC, 50/60 Hz |
| Pressure Vessel | SS 304 Grade |
| Testing | 40 PSI |
| Stainless Steel Top Lid | SS 304 Grade Stainless Steel. |
| Stainless Steel External Wall | SS 304 Grade |
| Basket | High Grade Stainless Steel |
| Model No. | LBX-301 | LBX-302 | LBX-303 | LBX-304 | LBX-305 | LBX-306 |
| Wall Locking Body | Double Wingnut Fully SS | Double Radial Fully SS | Double Radial SS Lining | Triple Wingnut Fully SS | Triple Radial Fully SS | Triple Radial SS Lining |
| Dimension (inch) | 10 x 18 | 12 x 22 | 14 x 22 | 16 x 24 | 18 x 24 | 22 x 30 |
| Inner Dimension | 250 x 450 | 300 x 550 | 350 x 550 | 400 x 600 | 450 x 600 | 550 x 750 |
| Capacity | 22 Liters | 40 Liters | 50 Liters | 78 Liters | 98 Liters | 180 Liters |
| Heater Load | 1.5 KW | 2 KW | 3 KW | 4 KW | 4 KW | 6 KW |
Optional (Semi Automatic):
- Automatic pressure control switch.
- Automatic low water cut off system.
- Microprocessor based digital temperature Indicator cum controller with set value and process valve/digital timer.
Optional (Fully Automatic):
- Automatic low water cut off system.
- Automatic Pressure control switch.
- Control: ON/OFF/T.P.
- Input: PT-100 Pressure Sensor for chamber.
- Purging Range: User settable.
- Post Sterilization: Drying Time: User settable.
- Boiler Control: User Settable.
- Buzzer: High/Low Alarm/Process End.
- Pressure Display.
- Sterilization cycle process inbuilt.
