| Test Method | End Point With Standard/Factor Two Point Kinetics (Fixed Time) Multipoint Kinetics Multistranded up to 8 standards Biochromatic, Dual Wavelength Absorbance Coagulation |
| Optical System | Principle: Photometric Analysis with Interference Absorbance Range: 0.0000-3.0000(Linearity: ± 1%, Repeatability: 0.001, Resolution Spectral Range Selection: Automatic Via Filter Wheel Wavelengths: 240, 405, 450, 505, 546, 578, 630 + 2 Free Positions ± 2CML Precision Ligth Source : 6V 10 W Long Life Tungsten Halogen Lamp |
| Detector | Photodiode. |
| Thermal System | Peltier Regulated 25°C, 30°C, 37°C & Room Temp |
| Accuracy | ± 0.3°C |
| Cuvettes | Flow Cell: Quartz 32 µlPath Lenth: 10mmRemovable Cuvette (Square and round) |
| Printer | Inbuilt Thermal Printer (57mm) |
| Display & Input System | 7.0 inch color touch screen External Keyboard, Mouse Facility |
| Suction System | Pressure Auto releasing Peristaltic Pump Suction Volume: 300µl to 3.0 ml Air Column facility after each sample to avoid carry over. |
| Test Parameter, Storage | Test Parameters: up to 300, 2,00,000 test results with editable patient information Storage of Quality Control and Standard results |
| DDR2 SD RAM | 1 G bit flash: 256MB ARM Cortex A8, 720 MHZ |
| Quality Control | Jew-jenning Charts Using Westgard’s Rule Auto Drawing of QC Figures |
| Operating Conditions | Temperature : 10°C~37°C Relative Humidity : <85% |
| Power Requirement | Voltage : 10-240 V AC (Auto Adaption) |
| Frequency | 50/60 HZ External Power Adaptor : 19V 4.7 Amp |
| Dimensions | 400 x 300 x 160 (LxBxH) |
| Weight | 6 Kg. |
Salient Features
- Highly Stable and accurate
- Absorbance Range upto 3,000
- Range Selection Automatic Via Filter Wheel
- Inbuilt Thermal Printer
- Up to 300 Test Parameters
- Storage of 2,00,000 test results with patient information
Standard Accessories
- Printer Paper Roll
- Removable Cuvette
- Optical Mouse
- External Key board
- AC Adapter
