| Test Method | End Point with standard/factor Two Point Kinetics (Fixed Time) Multipoint Kinetics Multi standard up to 8 standards Biochromic, Dual Wavelength |
| Absorbance | Optical System Principle: Photometric Analysis with Interference Filter Absorbance Range: 0.0000-3.0000 (Linearity: ±1%, Repeatability: 0.001, Resolution: 0.0001) Spectral Range Selection: Automatic Via Filter Wheel Wavelengths: 340, 405, 505, 546, 578, 630 nm +2 Free Positions, ± 2 CML Precision Light Source: 6 V 10 W Long Life tungsten Halogen Lamp Detector: Photodiode |
| Operating Conditions | * Temperature: 10°C-37°C * Relative Humidity: <85% |
| Quality Control | Lew-Jennings Chart Using Westgard’s Rule Auto Drawing of QC figures |
| Test Parameter, | Test Parameters: Up to 300 |
| Storage & Cpu | 1,000 test results with editable patient information Storage of Quality Control And standard results |
| Display & Input System | 4.3 inch color touch screen |
| Printer | Inbuilt Thermal Printer (57mm) |
| Suction System | Pressure Auto releasing Peristalic Pump Suction Volume: 300 µl to 3.0 ml Air Column facility after each sample to avoid carry over. |
| Cuvettes | Flow Cell: Quartz 32 µl Path Length: 10 mm Removable Cuvette (Square and round) |
| Thermal System | Peltier Regulated 25°C, 30°C, 37°C & Room Temperature Accuracy: ± 0.3°C |
| Power Requirement | Voltage: 100-240 V AC (Auto Adaption) Frequency: 50/60 HZ External Power Adaptor : 19 V 4.7 Amp |
| Dimensions | 300X250X140 (LxBxH) |
| Weight | 5 Kg |
