| Function | Basic, Wave length Scan, Multi Wavelength, Kinetics, Quantitative, DNA/Protein |
| Wavelength Range | 190-1100nm |
| Spectral Bandwidth | 0.5/1.0/1.8/2.0/4.0/5.0nm (Variable) |
| Optical System | Double Beam, Grating 1200 lines/mm |
| Wavelength Accuracy | ±0.1nm |
| Wavelength Repeatability |
±0.1 nm. |
| Scanning Speed | HI, MED & LOW, MAX. 3600 nm/min |
| Photometric Accuracy | ± 0.3 %T or ± 0.002 A/h@1A |
| Photometric Range | %T : 0-400% Abs : -0.3 to 4Abs Conc. : 0-9999 C |
| Stray Light | ≤0.03 %T @ 220nm & 360 nm |
| Stability | ±0.001 A/H @ 500 nm |
| Display | 5 Inches 320 x 240 Dots Graphical LCD |
| Baseline Flatness | ±0.001A/h (200-1000nm) |
| Sample Compartment | 8 cell with automatic cell changer 10 mm path length. |
| Light Source | Halogen & Deuterium Lamps (Pre-Aligned) |
| Printer Interface | Parallel port for dot matrix |
| Pc Connectivity | USB Port for PC Connectivity |
| Power | 230 V ± 10% AC, 50 Hz |
| Dimensions | Instrument : 760 x 550x 240 mm (LxBxH)Approx. |
| Weight | Instrument : 20.0 Kg. (Approx.) |
Salient Features
- Double Beam Optics
- 320 x 240 Dots Graphical LCD
- Auto Wavelength Setting
- On-screen Standard and Kinetic Curve Display
- Tungsten/Deuterium Lamp can be turned ON/OFF Individually to Extend Lifetime.
- Application Software provides complete control of the instrument from a
- computer through the built-in-USB Port
- Basic, WL Scan, Multi-Wavelength, Kinetic, Quantitative, DNA /Protein modes
- Pre-aligned design makes it convenient to change Lamps
- 8-Position Auto cell changer of 10mm path-length provided.
Standard Accessories
- Quartz Cuvettes – A Set of 2
- Glass Cuvettes – A Set of 4
- Instruction Manual
- Software Manual
- Software CD
- USB Data Cable for PC Connectivity
- Mains Lead
- Dust Cover
