| 4 Test Modes | Optical rotation, specific rotation, sugar degree and concentration |
| Light Source | LED |
| Measurement Range | ±45° (Optical rotation) +120° Z (sugar) |
| Wavelength | 589.3nm |
| Minimum Indicating Value | 0.001° (Optical rotation) |
| Accuracy | a) ±0.01 (-15° < optical rotation < +15°) b) +0.02° (optical rotation < -15° or optical rotation > +15°) Repeatability 0.002° (optical rotation) |
| Display | Colour Touch Screen |
| Test Tube | 200mm, 100mm |
| Sample Transmittance | >1% |
| Interface | USB & Rs232 |
| Operation Voltage | 220VAC±10%, 50Hz |
| Overall Dimensions | 850 x 500 x 470mm (LxBxH) |
| Weight (gross) | 38kg |
| Software | Yes |
Automatic Polarimeter Touch Screen
Automatic Polarimeter with Touchscreen is an innovative instrument for accurate and effortless measurement of optical rotation in liquid substances. This advanced instrument is excellently suited for pharmaceutical, chemical, food, and research laboratories alike. This automatic polarimeter combines automation with an intuitive touch interface for easy operation.
- Touch Screen Color Display
- Temperature Display
- Measurement of dark-colored sample
- USB & Rs232
- No warm-up time is required when instrument is switched on
- Insulated Sample chamber to keep sample temp. constant
- Photodiode Detector
