Microprocessor Dissolution Test Apparatus (Single Basket)

Our microprocessor dissolution system provides a sustainable, effective way of dissolving microprocessors and other integrated circuits. This state-of-the-art technology is ideal for electronics recycling, semiconductor production, and even precious metal recovery, as it reliably advanced technology will completely dissolve all micro components while being environmentally conscious.

Display	20×4 line alphanumeric LCD display with backlit
Keyboard	15 soft touch membrane type keys
LED’s	4 LED’s available for diﬀerent status indications 3 LED’s for. test status like Run, Alarm, End and one LED For Heater On/oﬀ Status.
Setup Data	Facility for 20 Diﬀerent test Setup available
Printer	Provision for the attachment of dot-matrix printer with centronics parallel port interface
Setup Data	Facility for 20 diﬀerent test setups available
Speed	25 to 160 RPM ±1 RPM
Accuracy	± 1 RPM
Resolution	1 RPM
Depth Adjustment	25 mm to 40 mm
Temp. Range	30°C – 50°C
Temp. Accuracy	± 0.2°C
Temp. Control	Microprocessor based using PT100/ Semiconductor sensor as per IP/USP
Heater	0.5 KW (Approx.)
Reaction Vessel	1000 ml jar with stirrer pedal and basket
Pc Connectivity	USB interface available
Power	230 V ± 10%, 50 Hz. AC
Dimensions	330 x 300 x 660 mm (LxBxH)
Weight	11 kg. (Approx.)

Standard Accessories

Main Unit with acrylic tank, rectangular cover
plate and water bath temperature sensor (T1) 1 No’s
Reaction vessel capacity 1000 ml 1 No’s
Round acrylic cover plate with hole and a large slit 1 No’s
Stirrer motor 1 No’s
S.S. Paddle, Stirrer Shaft and Clamp, S.S.
Wire mesh basket 1 No’s
S.S. support rod 1 No’s
External temperature sensor (T2) for vessel 1 No’s
Mains Lead 1 No’s
Instruction Manual 1 No’s
Dust Cover 1 No’s
