- Standard double wall fabrication.
- Exterior made of mild steel painted in Epoxy powder coating/stainless steel Insulation with High Grade ceramic wool for heat insulation & minimize thermal loss.
- Temperature range 100°C to 1200°C with working temperature of 1100°C.
- Heating Element made of Kanthal wire special high temperature alloy to ensure uniform distribution of heat.
- Microprocessor PID based Digital Temperature indicator cum controller.
- Works on 220/440 V 50Hz Single or 3 Phase power supply.
Optional:
a) Profile controller with Ramp and sock facility 16 steps.
Note: Other capacities of your requirement also available. GMP Model inner and outer ss complete also available.
| Model No. | Chamber size (HXWXD) mm inches | Capacity in liters (approx.) | |
| LBX-125 (A) | 255 X 100 X 100 | (9” X 4” X 4”) | 2 L |
| LBX-125 (B) | 250 X 125 X 125 | (10” X 5” X 5”) | 4 L |
| LBX-125 (C) | 300 X 150 X 150 | (12” X 6” X 6”) | 6.75 L |
| LBX-125 (D) | 300 X 200 X 200 | (12” X 8” X 8”) | 12 L |
| LBX-125 (E) | 450 X 225 X 225 | (18” X 9” X 9”) | 22 L |
| LBX-125 (F) | 300 X 300 X 300 | (12” X 12” X 12”) | 27 L |
| LBX-125 (G) | 450 X 300 X 300 | (18” X 12” X 12”) | 40 L |
| LBX-125 (H) | 600 X 300 X 300 | (24” X 12” X 12”) | 54 L |
