| Design Structure | Floor mounted |
| Air flow type | Automatic bypass type. |
| Construction (Exteriors) | Available in Two options. A) Stainless steel 304 grade outside & 316 grade SS inside. B) Epoxy powder coated 18 & 22 gauge galvanised steel structure. |
| Baffle arrangement | 2-point suction with baffle to ensure smooth and immediate exhaust of fumes. As per ASHRAE & EN norms. |
| Airfoil | Flush powder coated airfoil mounted on the worktop. |
| Worktop | Available in following options A) Chemical resistant splash & spillage proof jet black granite worktop. Sink, water tap with drain arrangement worktop fitted with oval shaped 100 X 200 mm PP cup-sink for drainage. B) Epoxy top C) Stainless steel 316 grade |
| Sash (Shutter) | Vertical Sliding counter balanced toughened glass (5MM thick) Clear sash open height-500-675 mm according to working size. |
| Service Fittings | Remotely operated colour coded (as per international standard) total three services valve with SS breaded flexible hose & brass fittings (1 water & 2 gases.) |
| Lighting | LED light for better illumination & less power consumption. |
| Electrical Utilities | 4 nos electrical sockets 15/5 amp & switches |
| Digital Air flow | Indicates the approximately face velocity of airflow with audible alarm for low airflow rates. |
| Centrifugal Blower | Silent high efficiency blower with chemical resistant impeller. Designed to give face velocity of 80 to 120 feet/minute (FPM) as per ANSI. |
| Air Suction capacity | Silent 650 CFM confirming to international face velocity norms. |
| Working Area Size | 60 X 60 X 60 cm. |
| Working Area Size | 90 X 60 X 60 cm. |
| Working Area Size | 120 X 60 X 60 cm. |
| Working Area Size | 150 X 60 X 60 cm. |
Fume Hood With Digital Air Flow Monitor And Exhaust System
As a leading Fume Hood With Digital Air Flow Monitor And Exhaust System Manufacturer, we provide high-quality, durable, and energy-efficient fume hoods designed for laboratories, research facilities, and industrial applications. Our fume hoods have been developed to ensure a safe working environment by removing hazardous fumes, vapors, and contaminants while maintaining optimal airflow control.
