Rated Power | 250W |
Input Voltage | 110/220-240v |
Input Frequency | 50Hz-60Hz |
Output Power | < 250w |
Frequency Tracking | Automatic tracking |
Power And Amplitude Adjust | 0-100% |
Packing Size(cm) | 32 x 46 x 42cm |
Machine Weight(kg) | 7 |
Sonotrode Length | 120mm |
Sonotrode Diameter | 8mm |
Sonotrode Frequency | 20KHz |
Operation Panel Display | Time setting working data |
Working Mode | 1s-99 hours with pause function continuous working |
Generator Protection | Built-in circuit, Overloading. Over temperature, Antishort – circuit, Soft start |
Cable Length | 2M |
Environment Temp | 0-40°C |
Relative Humidity | <=85% T=20°C |
Max Temp. Of Sonotrode | 100°C |
Max Pressure | 5Mpa |
Treatment Capacity Of Liquid | <10L/H |
Breaker Type For Batch | 20ML-200ML |
Accessories | Abs Soundproof Box, Stainless Steel Lifting Platform, 3 Fuse |
