| Fluoro Sensitivity | Full scale deflection obtained with 1 ppm quinine sulphate in 0.1 N sulphuric acid (Primary wavelength 360 nm) |
| Display | 3 digit 7 segment Red LED |
| Excitation Source | 12V, 50 W Tungsten Halogen Lamp |
| Sensitivity Range | Adjustment in 4 range |
| Primary Filters | Corning 5840 and Corning 5113 mounted on holders |
| Secondary Filters | Corning 4308, Corning 3486 and Corning 3385 mounted on holders |
| Detector | Highly sensitive wide range Photodiode/Photocell |
| Sample Test Tubes | 15mm (D) x 80mm (H) |
| Minimum Sample | 4 ml |
| Power | 230V ± 10% AC, 50Hz |
| Weight | 4.5 Kg (Approximately) |
| Dimensions | 260 x 335 x 160mm (LxBxH) |
| Accessories | Test Tubes (Set of 5), Dust Cover, Instruction Manual, Primary and Secondary Filters (Set of 5 Filters). |
Digital Photo Fluorometer
The Digital Photo Fluorometer delivers sophisticated fluorescence measurement capabilities, ensuring superior accuracy and dependability across various scientific and industrial applications.
- 3 Digit Seven Segment LED Display
- Covers Entire Visible Range
- Determines the concetration of Fluorophores & Quinine
