- Standard double wall fabrication.
- Inner chamber made of highly polished grade 304 Stainless steel.
- Exterior made of mild steel and painted in Epoxy powder coating.
- Wall gap filled with High Grade Glass Wool for heat insulation & minimize thermal loss.
- With two air circulation fans & digital voltmeter.
- Temperature Range +5°C to 50°C by digital PID temperature indicator cum controller.
- Temperature Accuracy ±1°C.
- Castor wheels for easy movement.
- Highly accurate PT-100 temperature sensor.
- Works on 230±10V/50Hz power supply.
Optional:
a) Co2 air mixer nozzle.
b) Internal illumination with 3 fluorescent tubes with 0-24 timer.
c) Automatic Voltage Stabilizer 3-5 KVA
d) PLC Controller with 21 CFR Software and data recorder
| Model No. | Inner Chamber Size (mm) (HXWXD) | Capacity (Cu.ft) | Capacity (Liters) |
| LBX-106 (A) | 455X410X610 | 4.1 | 112 |
| LBX-106 (B) | 505X415X830 | 6.1 | 171 |
| LBX-106 (C) | 565X565X865 | 10.1 | 280 |
| LBX-106 (D) | 650X580X900 | 12.1 | 336 |
| LBX-106 (E) | 700X650X900 | 15.1 | 420 |
